FAQ
  • Hardware
  • Software
  • Accessories
  • Scanning Tips
What is the accuracy of POP 2?
+
The accuracy of the output model can reach 0.1mm.
What is the resolution of RGB camera and depth camera?
+
RGB cameras have a resolution of 2 megapixels. The depth camera has a resolution of 1280 by 800.
What is the POP 2 scan frame rate?
+
Ten frames per second.
What is the technology behind POP 2?
+
POP 2 adopts infrared binocular structure technology, with higher output precision and better details of output model, making it easy to use.
What are the requirements for the configuration of the computer or mobile phone used for POP 2 3D scanning?
+
What is the difference between USB2.0 and 3.0?
+
The current/voltage required for POP 2 operation is 5V 1A, and the power output from USB 2.0 cannot meet the requirements of POP 2 operation. Therefore, when using computer scanning, it is necessary to ensure that the interface is USB 3.0. Therefore, in order to ensure the use of Android users, we have launched a 2-in-1 data cable.
What kind of computer is recommended for POP 2 to work smoothly?
+
Recommended computer: Windows10, 64bit,16G and above, I7.
Does POP 2 have 3D scanning software?
+
POP 2 comes with Revo Scan. In addition,Revopoint offers Revo Studio for post-processing.
Is the software free?
+
Scanning software is free. It can be downloaded from Revo’s website.
Is third-party software available for POP 2 scanning?
+

Can't.POP 2 can only be scanned with Revo Scan software, which can be downloaded from our official website. But you can use third-party software for post-processing.
What model formats can Revo Scan export?
+
The PLY. OBJ. And STL.
How do I export 3D scanned models on my phone or MAC?
+
Use the Share button.
Can POP 2 work with Revo Scan without Internet access?
+
You can. After software download, use USB connection to scan, not connected to the Internet can also be used.
What accessories can help 3D scan?
+
Turntable,LED light, 2-in-1 data line, mobile phone stand, marking point, etc.
Could you provide the specifications of the turntable?
+
Speed :2.5RPM(revolutions per minute) size :200 x 50mm rotation direction: counterclockwise maximum load capacity :5kg voltage input :DC 12V/1A
Turntable action?
+
Scanning small or medium-sized objects can be done faster with the help of a turntable.
The role of LED lights?
+
With LED lights, the texture color of the scanned model will be more uniform and vivid, and the details will be clearer. Body scans are also better. The LED lamp can avoid the situation that one side is dark and one side is bright.
Charge the LED lamp or replace the battery?
+
Rechargeable batteries.
What does the marker do?
+
Marker points are used to scan objects without geometric features. Flat objects such as boards or symmetrical objects such as balls and bowls are usually scanned by means of markers. Because the scanner splicing with the help of the unique pattern composed of adjacent markers, so the labeling time interval of 3-5cm, to be irregular paste.
Does the more frames scanned, the higher the scan accuracy?
+
Repeated scanning is not good for accuracy, and you can shorten the scanning distance if you want to achieve higher accuracy. It is best to scan each part of the object once, not repeatedly.
What if trace is lost during scanning?
+
When scanning, if the page shows a “trace lost” prompt, move the POP 2 scanner to the swept area (the blue area) and stand still for a few seconds to re-align. When the current frame shows green, the scan continues.
For large objects, is it possible to sweep them all at once?
+
You can. Large objects can be scanned all at once or in pieces and then pieced together using soft Revo Studio for post-processing. You can also open the scanned model and continue scanning.
How do I change the name and password of POP 2 Settings?
+
1) Download Revo Scan for Windows from our website; 2) Open Revo Scan, click “About”, and then click “Settings”; 3) Finally enter the new “name” and “password “.
How to sweep objects with sharp edges?
+
POP 2 is a high-precision 3D scanner that captures a lot of detail as it scans: the closer you get, the more detail you capture. It is recommended to scan objects with sharp edges at a distance of 200mm to 250mm to obtain more details.
