Can POP 4 be used outdoors?

Yes, POP 4 performs well in bright lighting conditions. In VCSEL rapid mode, it can operate stably in lighting of up to 100,000 lux. In multi-line laser scanning mode, it supports outdoor lighting conditions of up to 50,000 lux. For lighting above 50,000 lux, using a magnetic outdoor filter is recommended.

Does POP 4 have a built-in battery?

POP 4 does not have a built-in battery and must be powered via a USB-C to USB-C cable connected to an external power source. An optional Battery Grip can be used for portable wireless scanning.

How should I scan transparent or highly reflective objects?

Please use scanning spray when scanning transparent or specular surfaces. Scanning spray can be purchased from Revopoint's official online store.

What are the differences between the POP 4 and the POP 3 Plus scanners?

(1) Technology:

Do I need to use markers during scans?

In laser line scanning mode, using markers is a must. In structured light scanning mode, it depends on object features: for objects with rich geometric features, markers are not required; for featureless objects, markers are needed for stable tracking. When using markers, place them in an irregular pattern on the object surface and ensure that at least five markers are visible within each frame during scanning. In addition, POP 4's VCSEL rapid mode supports high-speed markerless scanning of featureless objects using feature tracking.

How do I use the calibration board?

It is recommended to enter the calibration program and calibrate your Revopoint 3D scanner using the Calibration Board before scanning. The steps are as follows:

(1) Connect the scanner to a PC using the USB Cable and open the Revo Scan 6 Software.

(2) Click the "Calibration" button in the lower left corner to enter the calibration program.

(3) Place the Calibration Board on a flat surface, ensuring the pattern on the board is clearly visible.

(4) Scan the QR code to import the Calibration Board's information, then check the scanner's accuracy. If the accuracy check fails, follow the on-screen instructions to complete the calibration.

How long does the Battery Grip power the POP 4?

The Battery Grip has a built-in 5500 mAh lithium battery, providing approximately 4 hours of runtime under normal usage conditions, making it suitable for extended outdoor operation.

Can I cast the screen of Revo Scan 6 to my phone wirelessly?

Yes. The Revo Mirror software enables casting of the PC scanning interface to your phone, allowing real-time preview and control from a mobile device.

Can I use the multi-line laser mode on a phone?

No, Multi-line laser mode requires a Wi-Fi connection to a PC, with the scan interface mirrored to the phone in real time. However, full-field structured light mode and VCSEL rapid mode can be used on a mobile device independently.

Do I need to purchase the software separately?

No, POP 4 comes with free scanning software Revo Scan 6. You can scan, edit, merge, and import/export models offline.
